PRO SDS max-4 Hammer Drill Bit

For rotary hammer drills

PRO SDS max-4

Lasts up to 1.5x longer than a Bosch SDS max-2 Drill Bit

Test results
  • Long Life drilling in reinforced concrete
  • High-quality, tough tungsten carbide ensures strength and durability
  • Fits all SDS max rotary hammer drills
  • May come in old design

Materials

Reinforced concrete
Concrete building block
Lime and sand bricks
Solid brick

Select options

Diameter (D) mm

Working length mm

Total length mm

Choose a pack size

Select options

Diameter (D) mm 13 options

Working length mm 2 options

Total length mm 4 options

Choose a pack size 1 Pcs

Available product options (44)
PRO SDS max-4 Hammer Drill Bit
from

Long Life drilling in reinforced concrete

Long Life drilling in reinforced concrete
  • 1

    High-quality, tough tungsten carbide ensures strength and durability

  • 2

    4-cutter head doesn't jam or break when you hit rebar

  • 3

    Deep channels remove dust effectively

PRO
Advantage

PRO SDS max-4 Hammer Drill Bit for Long Life Drilling in Reinforced Concrete

PRO SDS max-4 Hammer Drill Bit for Long Life Drilling in Reinforced Concrete

Reinforced concrete is a common material in infrastructure, commercial, and domestic construction. We made PRO SDS max-4 Hammer Drill Bits to help construction workers drill in it. The drill bits have a hardy 4-cutter design that prevents them from jamming or breaking when you hit rebar.

View more

Product Options

Available product options: 44

Part number Diameter (D) mm Working length mm Total length mm Pack quantity
2 608 685 860 16.00 200 340 1 Pcs Find a local dealer
2 608 685 861 16.00 400 540 1 Pcs Find a local dealer
2 608 685 862 18.00 200 340 1 Pcs Find a local dealer
2 608 685 863 18.00 400 540 1 Pcs Find a local dealer
2 608 685 864 20.00 200 320 1 Pcs Find a local dealer
2 608 685 865 20.00 400 520 1 Pcs Find a local dealer
2 608 685 866 22.00 200 320 1 Pcs Find a local dealer
2 608 685 867 22.00 400 520 1 Pcs Find a local dealer
2 608 685 868 25.00 200 320 1 Pcs Find a local dealer
2 608 685 869 25.00 400 520 1 Pcs Find a local dealer
2 608 685 870 28.00 200 320 1 Pcs Find a local dealer
2 608 685 871 28.00 400 520 1 Pcs Find a local dealer
2 608 685 872 30.00 200 320 1 Pcs Find a local dealer
2 608 685 873 30.00 400 520 1 Pcs Find a local dealer
2 608 685 874 32.00 200 320 1 Pcs Find a local dealer
2 608 685 875 32.00 400 520 1 Pcs Find a local dealer
2 608 685 876 35.00 400 520 1 Pcs Find a local dealer
2 608 685 877 40.00 400 520 1 Pcs Find a local dealer
2 608 706 774 12.00 200 340 1 Pcs Find a local dealer
2 608 706 775 12.00 400 540 1 Pcs Find a local dealer
2 608 706 776 14.00 200 340 1 Pcs Find a local dealer
2 608 706 777 14.00 400 540 1 Pcs Find a local dealer
2 608 706 778 16.00 200 340 1 Pcs Find a local dealer
2 608 706 779 16.00 400 540 1 Pcs Find a local dealer
2 608 706 780 18.00 200 340 1 Pcs Find a local dealer
2 608 706 781 18.00 400 540 1 Pcs Find a local dealer
2 608 706 783 20.00 200 320 1 Pcs Find a local dealer
2 608 706 784 20.00 400 520 1 Pcs Find a local dealer
2 608 706 786 22.00 200 320 1 Pcs Find a local dealer
2 608 706 787 22.00 400 520 1 Pcs Find a local dealer
2 608 706 789 24.00 200 320 1 Pcs Find a local dealer
2 608 706 790 24.00 400 520 1 Pcs Find a local dealer
2 608 706 791 25.00 200 320 1 Pcs Find a local dealer
2 608 706 792 25.00 400 520 1 Pcs Find a local dealer
2 608 706 795 28.00 200 320 1 Pcs Find a local dealer
2 608 706 796 28.00 400 520 1 Pcs Find a local dealer
2 608 706 798 30.00 200 320 1 Pcs Find a local dealer
2 608 706 799 30.00 400 520 1 Pcs Find a local dealer
2 608 706 800 32.00 200 320 1 Pcs Find a local dealer
2 608 706 801 32.00 400 520 1 Pcs Find a local dealer
2 608 706 803 35.00 400 520 1 Pcs Find a local dealer
2 608 706 806 40.00 400 520 1 Pcs Find a local dealer
2 608 833 963 24.00 200 320 1 Pcs Find a local dealer
2 608 833 964 24.00 400 520 1 Pcs Find a local dealer
