PRO SDS plus-5X Hammer Drill Bit

For rotary hammer drills

PRO SDS plus-5X

Lasts up to 1.5x longer than a Bosch SDS plus-1 Drill Bit

Test results
  • Long Life drilling in reinforced concrete
  • High-quality, tough tungsten carbide ensures strength and durability
  • Fits all SDS plus rotary hammer drills

Materials

Reinforced concrete
Concrete
Lime and sand bricks
Solid brick
Hard stone

Select options

Diameter (D) mm

Working length mm

Total length mm

Choose a pack size

Select options

Diameter (D) mm 22 options

Working length mm 8 options

Total length mm 12 options

Choose a pack size 1 Pcs

Available product options (77)
PRO SDS plus-5X Hammer Drill Bit
from

Long Life drilling in reinforced concrete

Long Life drilling in reinforced concrete
  • 1

    High-quality, tough tungsten carbide ensures strength and durability

  • 2

    4-cutter head doesn't jam or break when you hit rebar

  • 3

    4-flute design for efficient dust reduction

PRO
Advantage

PRO SDS plus-5X Hammer Drill Bit for Long Life Drilling in Reinforced Concrete

PRO SDS plus-5X Hammer Drill Bit for Long Life Drilling in Reinforced Concrete

Reinforced concrete is a common material in infrastructure, commercial and domestic construction, and workers such as electricians, plumbers or HVAC installers often need to drill into it. PRO SDS plus-5X Hammer Drill Bits are designed for this tough task, with a hardy 4-cutter design that doesn't jam or break when you hit rebar.

View more

Product Options

Available product options: 77

Part number Diameter (D) mm Working length mm Total length mm Pack quantity
2 608 706 863 5.00 50 110 1 Pcs Find a local dealer
2 608 706 864 5.00 100 160 1 Pcs Find a local dealer
2 608 706 865 5.00 150 210 1 Pcs Find a local dealer
2 608 706 869 5.50 50 110 1 Pcs Find a local dealer
2 608 706 870 5.50 100 160 1 Pcs Find a local dealer
2 608 706 871 5.50 150 210 1 Pcs Find a local dealer
2 608 706 875 6.00 50 110 1 Pcs Find a local dealer
2 608 706 876 6.00 100 160 1 Pcs Find a local dealer
2 608 706 877 6.00 150 210 1 Pcs Find a local dealer
2 608 706 878 6.00 200 260 1 Pcs Find a local dealer
2 608 706 881 6.50 50 110 1 Pcs Find a local dealer
2 608 706 882 6.50 100 160 1 Pcs Find a local dealer
2 608 706 883 6.50 150 210 1 Pcs Find a local dealer
2 608 706 884 6.50 200 260 1 Pcs Find a local dealer
2 608 706 886 7.00 50 110 1 Pcs Find a local dealer
2 608 706 887 7.00 100 160 1 Pcs Find a local dealer
2 608 706 888 7.00 150 210 1 Pcs Find a local dealer
2 608 706 890 8.00 50 110 1 Pcs Find a local dealer
2 608 706 891 8.00 100 160 1 Pcs Find a local dealer
2 608 706 892 8.00 150 210 1 Pcs Find a local dealer
2 608 706 893 8.00 200 260 1 Pcs Find a local dealer
2 608 706 894 8.00 250 310 1 Pcs Find a local dealer
2 608 706 895 8.00 300 360 1 Pcs Find a local dealer
2 608 706 896 8.00 400 460 1 Pcs Find a local dealer
2 608 706 898 9.00 100 160 1 Pcs Find a local dealer
2 608 706 899 9.00 150 210 1 Pcs Find a local dealer
2 608 706 901 10.00 50 110 1 Pcs Find a local dealer
2 608 706 902 10.00 100 160 1 Pcs Find a local dealer
2 608 706 903 10.00 150 210 1 Pcs Find a local dealer
2 608 706 904 10.00 200 260 1 Pcs Find a local dealer
2 608 706 905 10.00 250 310 1 Pcs Find a local dealer
2 608 706 906 10.00 300 360 1 Pcs Find a local dealer
2 608 706 907 10.00 400 460 1 Pcs Find a local dealer
2 608 706 909 11.00 100 160 1 Pcs Find a local dealer
2 608 706 910 11.00 150 210 1 Pcs Find a local dealer
2 608 706 911 11.00 200 260 1 Pcs Find a local dealer
2 608 706 912 12.00 100 160 1 Pcs Find a local dealer
2 608 706 913 12.00 150 210 1 Pcs Find a local dealer
2 608 706 914 12.00 200 260 1 Pcs Find a local dealer
2 608 706 915 12.00 250 310 1 Pcs Find a local dealer
2 608 706 916 12.00 300 360 1 Pcs Find a local dealer
2 608 706 917 12.00 400 460 1 Pcs Find a local dealer
2 608 706 920 13.00 100 160 1 Pcs Find a local dealer
2 608 706 921 13.00 150 210 1 Pcs Find a local dealer
2 608 706 922 13.00 200 260 1 Pcs Find a local dealer
2 608 706 923 14.00 100 160 1 Pcs Find a local dealer
2 608 706 924 14.00 150 210 1 Pcs Find a local dealer
2 608 706 925 14.00 200 260 1 Pcs Find a local dealer
2 608 706 926 14.00 250 310 1 Pcs Find a local dealer
2 608 706 927 14.00 300 360 1 Pcs Find a local dealer
2 608 706 928 14.00 400 460 1 Pcs Find a local dealer
2 608 706 931 15.00 100 160 1 Pcs Find a local dealer
2 608 706 932 15.00 200 260 1 Pcs Find a local dealer
2 608 706 933 15.00 400 460 1 Pcs Find a local dealer
2 608 706 934 16.00 150 210 1 Pcs Find a local dealer
2 608 706 935 16.00 200 260 1 Pcs Find a local dealer
2 608 706 936 16.00 250 310 1 Pcs Find a local dealer
2 608 706 937 16.00 300 360 1 Pcs Find a local dealer
2 608 706 938 16.00 400 460 1 Pcs Find a local dealer
2 608 706 940 17.00 150 210 1 Pcs Find a local dealer
2 608 706 941 17.00 250 310 1 Pcs Find a local dealer
2 608 706 943 18.00 150 200 1 Pcs Find a local dealer
2 608 706 944 18.00 250 300 1 Pcs Find a local dealer
2 608 706 945 18.00 400 450 1 Pcs Find a local dealer
2 608 706 946 18.00 550 600 1 Pcs Find a local dealer
2 608 706 948 19.00 250 300 1 Pcs Find a local dealer
2 608 706 950 20.00 150 200 1 Pcs Find a local dealer
2 608 706 951 20.00 250 300 1 Pcs Find a local dealer
2 608 706 952 20.00 400 450 1 Pcs Find a local dealer
2 608 706 954 22.00 200 250 1 Pcs Find a local dealer
2 608 706 955 22.00 400 450 1 Pcs Find a local dealer
2 608 706 957 24.00 200 250 1 Pcs Find a local dealer
2 608 706 958 24.00 400 450 1 Pcs Find a local dealer
2 608 706 959 25.00 200 250 1 Pcs Find a local dealer
2 608 706 960 25.00 400 450 1 Pcs Find a local dealer
2 608 706 961 26.00 200 250 1 Pcs Find a local dealer
2 608 706 962 26.00 400 450 1 Pcs Find a local dealer
