For hand-held circular saws
Outer diameter mm
Number of teeth
Width of cut (b1) mm
Choose a pack size
Outer diameter mm 165
Number of teeth 48
Width of cut (b1) mm 1.5
Choose a pack size 1 Pcs
available at Bosch Partner
Available from our partnersExpert for Wood Circular Saw Blade for cordless saws and dry-cutters maximises battery runtime
Available product options: 18
|
Part number
|
Outer diameter mm
|
Bore size mm
|
Width of cut (b1) mm / Base bl. thickness (b2) mm
|
Number of teeth
|
Pack quantity
|
Price
|
|
|---|---|---|---|---|---|---|---|---|
| 2 608 644 497 | 120 | 20 | 1.7/1.2 | 24 | 1 Pcs | 38.00 GBP | Available from our partners | |
| 2 608 644 498 | 136 | 20 | 1.5/1 | 24 | 1 Pcs | 39.00 GBP | Available from our partners | |
| 2 608 644 499 | 140 | 20 | 1.8/1.3 | 24 | 1 Pcs | 39.00 GBP | Available from our partners | |
| 2 608 644 500 | 140 | 20 | 1.8/1.3 | 42 | 1 Pcs | 45.00 GBP | Available from our partners | |
| 2 608 644 502 | 160 | 20 | 1.5/1 | 12 | 1 Pcs | 34.00 GBP | Available from our partners | |
| 2 608 644 503 | 160 | 20 | 1.5/1 | 24 | 1 Pcs | 40.00 GBP | Available from our partners | |
| 2 608 644 504 | 160 | 20 | 1.5/1 | 36 | 1 Pcs | 44.00 GBP | Available from our partners | |
| 2 608 644 505 | 160 | 20 | 1.5/1 | 48 | 1 Pcs | 47.00 GBP | Available from our partners | |
| 2 608 644 506 | 165 | 20 | 1.5/1 | 12 | 1 Pcs | 36.00 GBP | Available from our partners | |
| 2 608 644 507 | 165 | 20 | 1.5/1 | 24 | 1 Pcs | 42.00 GBP | Available from our partners | |
| 2 608 644 508 | 165 | 20 | 1.5/1 | 36 | 1 Pcs | 46.00 GBP | Available from our partners | |
| 2 608 644 509 | 165 | 20 | 1.5/1 | 48 | 1 Pcs | 49.00 GBP | Available from our partners | |
| 2 608 644 510 | 184 | 20 | 1.6/1 | 24 | 1 Pcs | 43.00 GBP | Available from our partners | |
| 2 608 644 511 | 184 | 20 | 1.6/1 | 48 | 1 Pcs | 51.00 GBP | Available from our partners | |
| 2 608 644 512 | 190 | 30 | 1.5/1 | 18 | 1 Pcs | 42.00 GBP | Available from our partners | |
| 2 608 644 513 | 190 | 30 | 1.5/1 | 24 | 1 Pcs | 44.00 GBP | Available from our partners | |
| 2 608 644 514 | 190 | 30 | 1.5/1 | 48 | 1 Pcs | 52.00 GBP | Available from our partners | |
| 2 608 644 515 | 190 | 30 | 1.5/1 | 60 | 1 Pcs | 55.00 GBP | Available from our partners |
out of products
| Part number 2608644497 | |
|---|---|
| Packaging type | Combined cardboard / plastic packaging, folding blister, with Euro hole |
| Pack quantity | 1 Pcs |
| Details | |
|---|---|
| Outer diameter mm | 120 |
| Bore size mm | 20 |
| Width of cut (b1) mm / Base bl. thickness (b2) mm | 1.7/1.2 |
| Number of teeth | 24 |
| Tooth shape | ATB |
| Max. rotation speed (RPM) | 12500 |
| Cutting result | Coarse cut |
| Hook angle ° α | 20 |
| Relief angle ° β | 12 |
| Part number 2608644498 | |
|---|---|
| Packaging type | Combined cardboard / plastic packaging, folding blister, with Euro hole |
| Pack quantity | 1 Pcs |
| Details | |
|---|---|
| Outer diameter mm | 136 |
| Bore size mm | 20 |
| Width of cut (b1) mm / Base bl. thickness (b2) mm | 1.5/1 |
| Number of teeth | 24 |
| Tooth shape | ATB |
| Max. rotation speed (RPM) | 10000 |
| Cutting result | Coarse cut |
| Hook angle ° α | 20 |
| Relief angle ° β | 12 |
| Bore with reduction ring mm | 15.875 |
| Part number 2608644499 | |
|---|---|
| Packaging type | Combined cardboard / plastic packaging, folding blister, with Euro hole |
| Pack quantity | 1 Pcs |
| Details | |
|---|---|
| Outer diameter mm | 140 |
| Bore size mm | 20 |
| Width of cut (b1) mm / Base bl. thickness (b2) mm | 1.8/1.3 |
| Number of teeth | 24 |
| Tooth shape | ATB |
| Max. rotation speed (RPM) | 10000 |
| Cutting result | Coarse cut |
| Hook angle ° α | 15 |
| Relief angle ° β | 15 |
| Bore with reduction ring mm | 12.7 / 10 |
| Part number 2608644500 | |
|---|---|
| Packaging type | Combined cardboard / plastic packaging, folding blister, with Euro hole |
| Pack quantity | 1 Pcs |
| Details | |
|---|---|
| Outer diameter mm | 140 |
| Bore size mm | 20 |
| Width of cut (b1) mm / Base bl. thickness (b2) mm | 1.8/1.3 |
| Number of teeth | 42 |
| Tooth shape | ATB |
| Max. rotation speed (RPM) | 10000 |
| Cutting result | Fine Cut |
| Hook angle ° α | 5 |
| Relief angle ° β | 15 |
| Bore with reduction ring mm | 12.7 / 11 |
| Part number 2608644502 | |
|---|---|
| Packaging type | Combined cardboard / plastic packaging, folding blister, with Euro hole |
| Pack quantity | 1 Pcs |
| Details | |
|---|---|
| Outer diameter mm | 160 |
| Bore size mm | 20 |
| Width of cut (b1) mm / Base bl. thickness (b2) mm | 1.5/1 |
| Number of teeth | 12 |
| Tooth shape | ATB |
| Max. rotation speed (RPM) | 8500 |
| Cutting result | Very coarse cut |
| Hook angle ° α | 25 |
| Relief angle ° β | 10 |
| Bore with reduction ring mm | 15.875 |
| Part number 2608644503 | |
|---|---|
| Packaging type | Combined cardboard / plastic packaging, folding blister, with Euro hole |
| Pack quantity | 1 Pcs |
| Details | |
|---|---|
| Outer diameter mm | 160 |
| Bore size mm | 20 |
| Width of cut (b1) mm / Base bl. thickness (b2) mm | 1.5/1 |
| Number of teeth | 24 |
| Tooth shape | ATB |
| Max. rotation speed (RPM) | 8500 |
| Cutting result | Coarse cut |
| Hook angle ° α | 25 |
| Relief angle ° β | 10 |
| Bore with reduction ring mm | 15.875 |
| Part number 2608644504 | |
|---|---|
| Packaging type | Combined cardboard / plastic packaging, folding blister, with Euro hole |
| Pack quantity | 1 Pcs |
| Details | |
|---|---|
| Outer diameter mm | 160 |
| Bore size mm | 20 |
| Width of cut (b1) mm / Base bl. thickness (b2) mm | 1.5/1 |
| Number of teeth | 36 |
| Tooth shape | ATB |
| Max. rotation speed (RPM) | 8500 |
| Cutting result | Fine Cut |
| Hook angle ° α | 15 |
| Relief angle ° β | 13 |
| Bore with reduction ring mm | 15.875 |
| Part number 2608644505 | |
|---|---|
| Packaging type | Combined cardboard / plastic packaging, folding blister, with Euro hole |
| Pack quantity | 1 Pcs |
| Details | |
|---|---|
| Outer diameter mm | 160 |
| Bore size mm | 20 |
| Width of cut (b1) mm / Base bl. thickness (b2) mm | 1.5/1 |
| Number of teeth | 48 |
| Tooth shape | ATB |
| Max. rotation speed (RPM) | 8500 |
| Cutting result | Fine Cut |
| Hook angle ° α | 10 |
| Relief angle ° β | 15 |
| Bore with reduction ring mm | 15.875 |
| Part number 2608644506 | |
|---|---|
| Packaging type | Combined cardboard / plastic packaging, folding blister, with Euro hole |
| Pack quantity | 1 Pcs |
| Details | |
|---|---|
| Outer diameter mm | 165 |
| Bore size mm | 20 |
| Width of cut (b1) mm / Base bl. thickness (b2) mm | 1.5/1 |
| Number of teeth | 12 |
| Tooth shape | ATB |
| Max. rotation speed (RPM) | 8500 |
| Cutting result | Very coarse cut |
| Hook angle ° α | 25 |
| Relief angle ° β | 10 |
| Bore with reduction ring mm | 15.875 |
| Part number 2608644507 | |
|---|---|
| Packaging type | Combined cardboard / plastic packaging, folding blister, with Euro hole |
| Pack quantity | 1 Pcs |
| Details | |
|---|---|
| Outer diameter mm | 165 |
| Bore size mm | 20 |
| Width of cut (b1) mm / Base bl. thickness (b2) mm | 1.5/1 |
| Number of teeth | 24 |
| Tooth shape | ATB |
| Max. rotation speed (RPM) | 8500 |
| Cutting result | Coarse cut |
| Hook angle ° α | 25 |
| Relief angle ° β | 10 |
| Bore with reduction ring mm | 15.875 |
| Part number 2608644508 | |
|---|---|
| Packaging type | Combined cardboard / plastic packaging, folding blister, with Euro hole |
| Pack quantity | 1 Pcs |
| Details | |
|---|---|
| Outer diameter mm | 165 |
| Bore size mm | 20 |
| Width of cut (b1) mm / Base bl. thickness (b2) mm | 1.5/1 |
| Number of teeth | 36 |
| Tooth shape | ATB |
| Max. rotation speed (RPM) | 8500 |
| Cutting result | Fine Cut |
| Hook angle ° α | 15 |
| Relief angle ° β | 13 |
| Bore with reduction ring mm | 15.875 |
| Part number 2608644509 | |
|---|---|
| Packaging type | Combined cardboard / plastic packaging, folding blister, with Euro hole |
| Pack quantity | 1 Pcs |
| Details | |
|---|---|
| Outer diameter mm | 165 |
| Bore size mm | 20 |
| Width of cut (b1) mm / Base bl. thickness (b2) mm | 1.5/1 |
| Number of teeth | 48 |
| Tooth shape | ATB |
| Max. rotation speed (RPM) | 8500 |
| Cutting result | Fine Cut |
| Hook angle ° α | 10 |
| Relief angle ° β | 15 |
| Bore with reduction ring mm | 15.875 |
| Part number 2608644510 | |
|---|---|
| Packaging type | Combined cardboard / plastic packaging, folding blister, with Euro hole |
| Pack quantity | 1 Pcs |
| Details | |
|---|---|
| Outer diameter mm | 184 |
| Bore size mm | 20 |
| Width of cut (b1) mm / Base bl. thickness (b2) mm | 1.6/1 |
| Number of teeth | 24 |
| Tooth shape | ATB |
| Max. rotation speed (RPM) | 8000 |
| Cutting result | Coarse cut |
| Hook angle ° α | 25 |
| Relief angle ° β | 10 |
| Bore with reduction ring mm | 16 |
| Part number 2608644511 | |
|---|---|
| Packaging type | Combined cardboard / plastic packaging, folding blister, with Euro hole |
| Pack quantity | 1 Pcs |
| Details | |
|---|---|
| Outer diameter mm | 184 |
| Bore size mm | 20 |
| Width of cut (b1) mm / Base bl. thickness (b2) mm | 1.6/1 |
| Number of teeth | 48 |
| Tooth shape | ATB |
| Max. rotation speed (RPM) | 8000 |
| Cutting result | Fine Cut |
| Hook angle ° α | 10 |
| Relief angle ° β | 15 |
| Bore with reduction ring mm | 16 |
| Part number 2608644512 | |
|---|---|
| Packaging type | Combined cardboard / plastic packaging, folding blister, with Euro hole |
| Pack quantity | 1 Pcs |
| Details | |
|---|---|
| Outer diameter mm | 190 |
| Bore size mm | 30 |
| Width of cut (b1) mm / Base bl. thickness (b2) mm | 1.5/1 |
| Number of teeth | 18 |
| Tooth shape | ATB |
| Max. rotation speed (RPM) | 8000 |
| Cutting result | Very coarse cut |
| Hook angle ° α | 25 |
| Relief angle ° β | 10 |
| Bore with reduction ring mm | 20 |
| Part number 2608644513 | |
|---|---|
| Packaging type | Combined cardboard / plastic packaging, folding blister, with Euro hole |
| Pack quantity | 1 Pcs |
| Details | |
|---|---|
| Outer diameter mm | 190 |
| Bore size mm | 30 |
| Width of cut (b1) mm / Base bl. thickness (b2) mm | 1.5/1 |
| Number of teeth | 24 |
| Tooth shape | ATB |
| Max. rotation speed (RPM) | 8000 |
| Cutting result | Coarse cut |
| Hook angle ° α | 25 |
| Relief angle ° β | 10 |
| Bore with reduction ring mm | 20 |
| Part number 2608644514 | |
|---|---|
| Packaging type | Combined cardboard / plastic packaging, folding blister, with Euro hole |
| Pack quantity | 1 Pcs |
| Details | |
|---|---|
| Outer diameter mm | 190 |
| Bore size mm | 30 |
| Width of cut (b1) mm / Base bl. thickness (b2) mm | 1.5/1 |
| Number of teeth | 48 |
| Tooth shape | ATB |
| Max. rotation speed (RPM) | 8000 |
| Cutting result | Fine Cut |
| Hook angle ° α | 15 |
| Relief angle ° β | 13 |
| Bore with reduction ring mm | 20 |
| Part number 2608644515 | |
|---|---|
| Packaging type | Combined cardboard / plastic packaging, folding blister, with Euro hole |
| Pack quantity | 1 Pcs |
| Details | |
|---|---|
| Outer diameter mm | 190 |
| Bore size mm | 30 |
| Width of cut (b1) mm / Base bl. thickness (b2) mm | 1.5/1 |
| Number of teeth | 60 |
| Tooth shape | ATB |
| Max. rotation speed (RPM) | 8000 |
| Cutting result | Fine Cut |
| Hook angle ° α | 10 |
| Relief angle ° β | 15 |
| Bore with reduction ring mm | 20 |
