For cordless handheld circular saws
Outer diameter mm 190
Number of teeth 54
Width of cut (b1) mm 1.8
Choose a pack size 1 Pcs
Expert for Aluminium Circular Saw Blade for cordless saws and dry-cutters maximises battery runtime
Available product options: 8
|
Part number
|
Outer diameter mm
|
Bore size mm
|
Width of cut (b1) mm / Base bl. thickness (b2) mm
|
Number of teeth
|
Pack quantity
|
Price
|
|
|---|---|---|---|---|---|---|---|---|
| 2 608 644 534 | 120 | 20 | 1.8/1.2 | 42 | 1 Pcs | 52.00 £ | Available from our partners | |
| 2 608 644 535 | 136 | 20 | 1.6/1 | 48 | 1 Pcs | 55.00 £ | ||
| 2 608 644 536 | 140 | 20 | 1.8/1.3 | 48 | 1 Pcs | 55.00 £ | ||
| 2 608 644 537 | 150 | 20 | 1.8/1.3 | 48 | 1 Pcs | 55.00 £ | Available from our partners | |
| 2 608 644 538 | 160 | 20 | 1.8/1.3 | 54 | 1 Pcs | 57.00 £ | ||
| 2 608 644 539 | 165 | 20 | 1.8/1.3 | 54 | 1 Pcs | 63.00 £ | ||
| 2 608 644 540 | 184 | 20 | 1.8/1.3 | 54 | 1 Pcs | 61.00 £ | ||
| 2 608 644 541 | 190 | 30 | 1.8/1.3 | 54 | 1 Pcs | 62.00 £ |
out of products
| Part number 2608644534 | |
|---|---|
| Packaging type | Combined cardboard / plastic packaging, folding blister, with Euro hole |
| Pack quantity | 1 Pcs |
| Details | |
|---|---|
| Outer diameter mm | 120 |
| Bore size mm | 20 |
| Width of cut (b1) mm / Base bl. thickness (b2) mm | 1.8/1.2 |
| Number of teeth | 42 |
| Tooth shape | HLTCG |
| Max. rotation speed (RPM) | 12500 |
| Cutting result | Fine Cut |
| Hook angle ° α | 0 |
| Relief angle ° β | 15 |
| Part number 2608644535 | |
|---|---|
| Packaging type | Combined cardboard / plastic packaging, folding blister, with Euro hole |
| Pack quantity | 1 Pcs |
| Details | |
|---|---|
| Outer diameter mm | 136 |
| Bore size mm | 20 |
| Width of cut (b1) mm / Base bl. thickness (b2) mm | 1.6/1 |
| Number of teeth | 48 |
| Tooth shape | HLTCG |
| Max. rotation speed (RPM) | 10000 |
| Cutting result | Fine Cut |
| Hook angle ° α | 0 |
| Relief angle ° β | 15 |
| Bore with reduction ring mm | 15.875 |
in stock
| Part number 2608644536 | |
|---|---|
| Packaging type | Combined cardboard / plastic packaging, folding blister, with Euro hole |
| Pack quantity | 1 Pcs |
| Details | |
|---|---|
| Outer diameter mm | 140 |
| Bore size mm | 20 |
| Width of cut (b1) mm / Base bl. thickness (b2) mm | 1.8/1.3 |
| Number of teeth | 48 |
| Tooth shape | HLTCG |
| Max. rotation speed (RPM) | 10000 |
| Cutting result | Fine Cut |
| Hook angle ° α | -5 |
| Relief angle ° β | 15 |
| Bore with reduction ring mm | 12.7; 10 |
in stock
| Part number 2608644537 | |
|---|---|
| Packaging type | Combined cardboard / plastic packaging, folding blister, with Euro hole |
| Pack quantity | 1 Pcs |
| Details | |
|---|---|
| Outer diameter mm | 150 |
| Bore size mm | 20 |
| Width of cut (b1) mm / Base bl. thickness (b2) mm | 1.8/1.3 |
| Number of teeth | 48 |
| Tooth shape | HLTCG |
| Max. rotation speed (RPM) | 10000 |
| Cutting result | Fine Cut |
| Hook angle ° α | 0 |
| Relief angle ° β | 15 |
| Bore with reduction ring mm | 15.875; 10 |
| Part number 2608644538 | |
|---|---|
| Packaging type | Combined cardboard / plastic packaging, folding blister, with Euro hole |
| Pack quantity | 1 Pcs |
| Details | |
|---|---|
| Outer diameter mm | 160 |
| Bore size mm | 20 |
| Width of cut (b1) mm / Base bl. thickness (b2) mm | 1.8/1.3 |
| Number of teeth | 54 |
| Tooth shape | HLTCG |
| Max. rotation speed (RPM) | 8500 |
| Cutting result | Fine Cut |
| Hook angle ° α | 0 |
| Relief angle ° β | 15 |
| Bore with reduction ring mm | 15.875 |
in stock
| Part number 2608644539 | |
|---|---|
| Packaging type | Combined cardboard / plastic packaging, folding blister, with Euro hole |
| Pack quantity | 1 Pcs |
| Details | |
|---|---|
| Outer diameter mm | 165 |
| Bore size mm | 20 |
| Width of cut (b1) mm / Base bl. thickness (b2) mm | 1.8/1.3 |
| Number of teeth | 54 |
| Tooth shape | HLTCG |
| Max. rotation speed (RPM) | 8500 |
| Cutting result | Fine Cut |
| Hook angle ° α | 0 |
| Relief angle ° β | 15 |
| Bore with reduction ring mm | 15.875 |
in stock
| Part number 2608644540 | |
|---|---|
| Packaging type | Combined cardboard / plastic packaging, folding blister, with Euro hole |
| Pack quantity | 1 Pcs |
| Details | |
|---|---|
| Outer diameter mm | 184 |
| Bore size mm | 20 |
| Width of cut (b1) mm / Base bl. thickness (b2) mm | 1.8/1.3 |
| Number of teeth | 54 |
| Tooth shape | HLTCG |
| Max. rotation speed (RPM) | 8000 |
| Cutting result | Fine Cut |
| Hook angle ° α | 0 |
| Relief angle ° β | 15 |
| Bore with reduction ring mm | 16 |
in stock
| Part number 2608644541 | |
|---|---|
| Packaging type | Combined cardboard / plastic packaging, folding blister, with Euro hole |
| Pack quantity | 1 Pcs |
| Details | |
|---|---|
| Outer diameter mm | 190 |
| Bore size mm | 30 |
| Width of cut (b1) mm / Base bl. thickness (b2) mm | 1.8/1.3 |
| Number of teeth | 54 |
| Tooth shape | HLTCG |
| Max. rotation speed (RPM) | 8000 |
| Cutting result | Fine Cut |
| Hook angle ° α | 0 |
| Relief angle ° β | 15 |
| Bore with reduction ring mm | 20 |
in stock
